Thông tin chi tiết sản phẩm:
|
| kết cấu của vật liệu: | Thép | Năng lực sản xuất: | 1500 tờ |
|---|---|---|---|
| Lớp tự động: | Tự động | Chức năng: | Bảng xi măng sợi |
| Làm nổi bật: | fiber cement board machine,sheet forming machine |
||
| Item |
Unit |
Standard Fiber Reinforced Calcium Silicate Board |
| Density | g/cm 3 | <1.3 |
| Anti-bend strength | MPa | >9 |
| Heat conduction modulus | w/m.k | <0.29 |
| Anti-impact strength | kJ/mm 2 | >2.0 |
| Pull force of screw | N/mm | >75 |
| Dry shrinkage rate | % | <0.2 |
| Non-burn performance | In accordance with standard GB8624 First Class Non-burn Material |
| , but no water drop | |||||
| High density | 1.4≤ D≤ 1.7 | ≤ 28 | __ |
| Compressive Strength | ~20 MPa (3, 000 PSI) |
| Impact Resistance | > 6 kJ/m2 |
| Tensile Strength | > 5.5 MPa |
| Density (Specific Mass) | ~1000 Kg/m3 (+/-< 2%) |
| Moisture Absorption | ~26% maximum saturation (slow absorption rate) |
| Moisture Content | ~6% |
| Water Vapour Diffusion | ~28 / 35 |
| Specific Heat | ~930 J/kgK |
| Thermal Conductivity | ~0.44 W / mK |
| Modulus of elasticity | ~6045 N/mm2 |
| Flexibility UNI E 12372 |
~20.1 N/mm2 maximum 12mm x 1220 x 2440 = 10 N/mm2 |
| Surface Alkalinity | ~10 Ph |
| Thermal Expansion Hot/Cold | 0, 01 mm/mC (from temp +20C to -20C) |
| Expansion in Water | less than < 0.02% from ambient to saturation |
| Freeze / Thaw - UNI EN 520 | 100 cycles without notable effects |
| Frost Resistance | no water drops form on surface |
| Combustibility / Fire Ratings | non-combustible / 12mm exceeds 1 hr fire rating |
| Dimensional tolerance | thick 0.2mm / width 2mm / length 3mm / Sq. 3mm |
| Toxicity Pollutants Heavy Metals - UNI EN 12457-2 | Below measurable levels of test instruments |
| Asbestos Analysis | Absent - not measurable |
| Formaldehyde Analysis | Absent - not measurable |
| Sound Attenuation (9mm) | tested design ASTM E90 = STC 48, 50, 55, & 60 |
| Color | Slate Grey and Chalk White |
| Surface texture | smooth one side; uniform machine textured back |
| Basic Compounds | (MgO)+(natural silicates)+(glass fibre)+(wood fibre) |
Người liên hệ: Kevin
Tel: 86-18254101233
Fax: 86-531-82985999
