Hydraulic System GRC Board Roof Panel Roll Forming Machine High Stable Performance

Hydraulic System GRC Board Roof Panel Roll Forming Machine High Stable Performance

GRC board production line Construction Material Making  Larger Capacity for 1500 Sheets

Content Design (1) raw material supply

              (2) ingredients,mixing machine

              (3) molding equipment,auxiliary equipment

             (4) maintenance drying equipment

             (5) second maintenance area

             (6) drying,choosing,cutting,Edge banding machine,packing equipment

(1) raw materials supply

1.1 The main raw material of magnesium oxide board :

   Magnesium oxide,Magnesium chloride, None-woven fabric, Glass

firber.,Sawdust ,Straws and Perlite

1.2  magnesium oxide warehouse

1.3 magnesium chloride solution pool(suggestion uses two dissolve pool and matches mixing equipment)

1.4 pearlite storage(independent) different thickness of the plank use different degree of material.

1.5 sawdust storage(independent) different thickness of the plank uses different degree of material.

1- The concrete product produced by HQJ machine can also be used as roof of houses with the materials of cement, sand and aggregate.

2- HQJ panel machine is a movable producing panel machine which need platform to move during producing.

3- Thin steel wire is put inside the panel in advance before producing. And this process is easy, not using tensile machine.

4-The machine is applied to the high tech. Extrusion technique can make the panels more density and surface much smoother.

Providing overall solutions about mgo board, EPC project, seperate machinery, products export. Including technology design, manufacturing, installation,commissioning, training, service, etc.

Outline.Length: 18m width: 1.5m

Output: 1800peices per day (8 working hours).

Operator: One production line needs 15-18 workers.

Specification of board: 3,4,5,6,8,9,10,12,15mm thickness.

This production can produce two kinds of MGO board: common MGO board and coated MGO board.

Such board making machine has one 3KW timing electromotor and one 2.2KW electromotor.

 After-sale
After purchased the equipment, we will teach relevant technology for free, and will go to your factory for installation and testing until you can produce the qualified product by yourself. Our company will train 2-3 technical personnel for free until he can get the skill. We will take responsibility for provide technical consultation and following-up service for a long time, the equipment warranty period is one year.

1. We offer Technical Support until the workers know how to operate.

2. We provide free answers about all kinds of questions about the production,if   necessary,pls call us freely.

3. We provide lifelong guidance about our equipment.visit client in regular times.

4. Provide equipment easy-broken pasts year in year.to insure your machine can working continuously.

we sincerely hope to establish relationship with company both home and aboard to get a better future hand in hand.

Our company produces the paper face plasterboard of saving energy and reducing consumption, and safety production, environmental protection, the reduction of labor intensity, improve automation, improve the yield, improve the overall quality of the product research and development and implementation, have made a great breakthrough, completely change the original ingredients forming and drying process, in the same output is the same, the original equipment can save investment is 50%, compared with a 50% saving electricity coal saving 30%, commissioning, 50% lower cost, and greatly improve the product quality.

The company can design and manufacture with annual capacity of 2 million m2 to 20 million m2 production equipment.

the paper face plasterboard drying methods can choose:

Test we can do before delivery:


mgo board machinemgo board production line

Magnesium oxide board have been used primarily as fireproof materials for walls and ceilings in office buildings, apartment complexes, residential constructions, hotels, theatres, restaurants, railway stations, airports, scientific research institutions, schools, hospitals, and stadiums. Some patterned products have been used as decorative boards.

It also can be used as an interlayer for building, movable partitions, sound-absorbing structures, sound insulation structures, heat insulation and preservation structures, sign boards, fireproof partition walls, low fencing partitions, fireproof pipeline, fireproof doors, cornice baffle boards, public restroom dividers, baseboards, truck cabinets and billboards etc.
