Thông tin chi tiết sản phẩm:
|
| Nguyên liệu thô: | mgo/mgcl2/mùn cưa | Kiểu: | Đứng miễn phí |
|---|---|---|---|
| Tính thường xuyên: | 50Hz | Dung tích: | 1100 tờ/ca |
| Bảo hành: | 1 năm | Ứng dụng: | làm bảng |
| Quá trình chính: | Hình thành | ||
| Làm nổi bật: | Construction Material Making Machinery,polyurethane sandwich panel machine |
||
Manufacture Fire Resistant Magnesium Sheet Equipment for Construction Building
1.product
The machine adopts PLC and touch screen control, automatic filling, electronic weighing, temperature control, material level control to realize automatic production.
The machine is complete with Screw Conveyor and Electronic Weighing system.
2.product model
According to different production,our equipment has 6 models for large-scale and small-scale.our all equipment can produce board with same quality and specification but different production.the board with the thickness of 2-25mm, the biggest width of 1,300mm and unlimited length .so you can adjust the thickness of board at will. the standard specification of the board is 1.22m*2.44m.
| frequency | pressure | equipment | rooms | capacity |
| 50HZ | 380V | 1.7million M2 | 12M*80M/9M*40M | 10KW-15KW |
3.Technology index
| serial number | Inspection items |
Standard requirement (thickness 8mm) |
inspection results | |
| 1 | Flexural strength | >8.0 | 10.3 | |
| 2 | Impact strength | >1.5 | 4.84 | |
| 3 | performance density | 0.7<p<1.0 | 0.92 | |
| 4 | Back to halogen resistance | No water, no get damp | No water, no get damp | |
| 5 | Dry shrinkage | <0.3 | 0.21 | |
| 6 | Wet bilge rate | <0.6 | 0.40 | |
| 7 | With screw force | >15 | 61 | |
| 8 | The chloride ion content | <10 | 2.96 | |
| 9 | The factory of moisture content | <8 | 7.5 | |
|
10 |
incombustible |
The average temperature in the furnace |
<50 |
8 |
| The average combustion duration |
<20 |
0 |
||
| The average mass loss rate |
<50 |
47.5 |
||
4. Structure principle and specification
Production line for mgo board with fashionable design ,reasonable structure, stable running manufactures even thickness board in large production once through double ways roll-in technology .This production line is equipped with shaking device which can remove inside and outside air bubble .so our board is more compact .in addition,we use the no-woven cloth as the separating film to increase the toughness and the strength of the board .The machine can be adjusted arbitrarily ,and then produce the board with the thickness of 2-25mm,the biggest width of 1,300mm and unlimited length .so you can adjust the thickness of board at will.
5. Excellect service
1)Fully life-cycle value services
Our company provides mgo board production line design ,cost accounting,installation and operation,equipment maintenance and the whole life cycle techincal support
2)all-around thechnical service
We provide technical formula for clients,to help clients to occupy the leading position in the market.
3)complete data specification
Provide production line equipment technical data and instructions,and provide the mgo board production line formula.
4)quality commitment
The company regards product quality as the lives of enterprise,the main components and wearing parts are made of high quality wear-resistant materials and advanced processing technology,so that the equipment endurable and wear resisting ,wearing parts warranty for one year.
