Precast Eps Concrete Sandwich Wall Panel Making Machine / Production Line Fully Automatic
Chuangxin Automatic precast EPS concrete sandwich wall panel making machine/ production line
Introduction of wall panel machine:
We are professional manufacturer of different kinds of lightweight wall panel machines----precast hollow core wall panel machine, eps concrete sandwich wall panel machine, ceramsite block machine, fence wall panels made of construction waste etc. Our advantage is that we not only make the machines, but also make the panels, so we have rich experience.The most important part of our advantage is not only about the machine, but also about the formulation. How to make the best-quality panels at the lowest price according to the materials which the customers have in their countries is our main purpose. We can make the best formulation for our customers because we have rich experience in this field. The materials of making this kind of panels can be cement, fly ash, leca, perlite, eps, gypsum, Mgo, Mgcl2/Mgso4, wood saw powder, crushed plant straws, etc.
Feature of wall panel making machine
1. Anti-earthquake with light weight: In view of its weight per unit area is only 1/10 of red brick wall, the product has good anti-earthquake performance. It can be used at low-rise building and high-rise building, and it is preferred to be used at workshop with steel frame structure. It can replace the color steel plate with its better performance.
2. Fast and convenient operation: It can be installed by board or combination with the dry method, and the product can be nailed, cut, planed, drilled and stuck.
3. Low comprehensive cost: The product is made of agricultural and industrial wastes, so the production cost is low. With the low load of girder and short construction period, it can reduce over 20% of engineering cost after compared with solid brick and hollow brick.
4. Energy-saving and environmental protection: The production processing need no high temperature and high pressure. Being a green environmental-protection energy-saving building materials, the product has no toxicity, harm, pollution and radioactivity.
5. Increasing the usage area: Under the same condition of heat-preserving and sound insulation, with the thinner plate, the product can increase over 10% usage area after compared with the same building.
6. Having the following features: fireproofing, water-proof, anti-impact, acid & alkali resistant and anti-aging.
Specification of wall panel making machine
| No. |
Test Item |
National standard |
Wall panel testing |
| 1 |
Compressive strength |
≥3.5MPa |
≥3.7MPa |
| 2 |
Drying shrinkage |
≤0.6mm/m² |
0.37mm/ m² |
| 3 |
Hanging force |
≥1000N 24hours
No 0.55mm crack in 24hours
|
≥1000N 24hours
No 0.55mm crack in 24hours
|
| 4 |
shock resistance |
without crack shocked
by 30kgs sandbag five times
|
without crack shocked
by 30kgs sandbag five times
|
| 5 |
The bending failure load |
≥1.5 times of the self
weight of the wall panel
|
≥2.5 times of the self weight
of the wall panel
|
| 6 |
radioactivity |
Inner radiation index Ira≤1.0
Outer radiation index IY≤1.3
|
Inner radiation index Ira≤1.0
Outer radiation index IY≤1.3
|
| 7 |
density |
≤90kgs/m² |
≤43kgs/m² |
| 8 |
Air insulation of sound |
≥35dB |
≥43dB |
| 9 |
Fire resistance limit |
≥1 h |
≥ 1h |
|
